Medicine Vending Machine (AMVM-40PC)

Get a Price/Quote

MOQ : 1 Number

Medicine Vending Machine (AMVM-40PC) Specification

Product Type
Automatic Medicine Vending Machine

Material
CRCA Steel body

Automation
Fully Automatic

Display
7-inch Touch Screen Display

Voltage
230V AC, 50Hz

Power
150 W

Capacity
40 product channels (can hold approx. 400-600 strips)

Temperature
15C - 25C (controlled ambient)

Size
1800 mm (H) x 900 mm (W) x 400 mm (D)

Weight
Approx. 150 kg

Color
White & Blue

Payment Options
Accepts currency notes, coins, debit/credit cards, UPI, and wallets

Security
Auto door lock, alarm system, CCTV provision

Inventory Management
Real-time stock updates with notification alerts

Connectivity
Wi-Fi, LAN, GSM/4G enabled for remote monitoring

Operating Environment
Indoor air conditioned or standard pharmacy environments

Compliance
Meets medical device safety and electrical standards (IEC/ISO)

Dispensing Mechanism
Electro-mechanical motorized channels

Installation
Floor standing, plug & play with minimal setup

Reporting
Sales, inventory, and usage reports downloadable via USB & cloud

User Interface
Multi-language support, Touch-based interactive GUI

About Medicine Vending Machine (AMVM-40PC)

Metal Enclosure: Mild-Steel powder coated cabinet.
No of Product selections: 40 standard (5 x 8 Spirals)
Product Holding Capacity: 550 to 600 items depending on the size
Product Type: 3 na wh eaeke. bottles, Boxes, Tubes and pouch pack
Cash Acceptor: INR Notes of All denominations
Cash Dispenser: Available for one Denomination with a capacity to hold 700 notes.
Coin Acceptor: INR Coins of All denominations
Coin Dispenser Any one denomination of INR 1, 2, 5 or 10
Coin Dispenser capacity: 500 Nos.
Protocol : Serial Port (RS-232C)
Connectivity: Wi-fi, Ethernet (LAN), Bluetooth
User Interface: 15.6 (or) 19 Inch Capacitive Touch Screen
Report Logs: Available through password protected settings Menu for on screen view.
Summary Report : Available through printer.
Construction: Full Toughened Glass Front Door with White LED lighting for better visibility and showcasing the available products. Software is programmed with option to play Educational and Health awarness videos when in idle condition
Operating Environment : Ambient room temperature
Power Supply 150V to 230V, SAmps AC, 50Hz,
Power Consumption: 120W (peak)
Back up : UPS available as an add on option
Dimensions (Hx WxD)in mm : 1820mm(H) 1010mm(W) x 815mm(D),
Weight : 170kg Approximate.

Advanced User Experience

The AMVM-40PC offers a modern, touch-based graphical user interface with multilingual support, making it accessible to a wider range of users. Its interactive display offers a seamless and intuitive journey for purchasing medications securely and efficiently, reducing wait times and improving customer satisfaction.

Comprehensive Payment Flexibility

This vending machine supports various payment methods including cash, cards, UPI, and digital wallets. Such versatility ensures effortless transactions for users and helps pharmacies accommodate the diverse preferences of customers across India, thereby enhancing convenience and accessibility.

Robust Inventory & Security Control

Real-time inventory management provides instant stock notifications and automated alerts. For safety, the AMVM-40PC has an auto door lock, alarm, and CCTV provision, safeguarding medicines and transactions. Remote connectivity further allows for easy monitoring and usage tracking, both on-site and from afar.

FAQ's of Medicine Vending Machine (AMVM-40PC):

Q: How does the AMVM-40PC Medicine Vending Machine operate for users?

A: Users interact with the 7-inch touch screen to select medicines, choose their preferred language, and follow on-screen prompts. Payment can be made using cash, cards, UPI, or wallets, after which the machine dispenses the selected items automatically.

Q: What payment options are available on the AMVM-40PC?

A: The machine accepts currency notes, coins, debit and credit cards, UPI, and multiple digital wallets, facilitating quick and easy transactions for a broad range of customers.

Q: Where can the AMVM-40PC vending machine be installed?

A: It is designed for indoor environments such as pharmacies, hospitals, and clinics-both air-conditioned and standard setups-where controlled ambient temperatures (15C - 25C) can be maintained.

Q: What security features does the machine offer?

A: Security is ensured through an automatic door lock, built-in alarm system, and provisions for CCTV installation. These features protect both medication and financial transactions against misuse or theft.

Q: How does the inventory management system function?

A: The AMVM-40PC provides real-time stock updates and notification alerts for low inventory levels. Pharmacy managers can also download detailed sales, inventory, and usage reports through USB or via cloud connectivity.

Q: What are the benefits of using the AMVM-40PC in a pharmacy or healthcare setting?

A: The machine minimizes manual handling, reduces waiting time for customers, ensures compliance with medical standards, and offers flexible payment and language options, thus improving efficiency and accessibility.
